Architecture
The Bravura One mobile proxy server communicates with the Mobile Worker Service and allows the Bravura One app on mobile devices using a home or public WiFi hot spot or a cell phone data plan to access Bravura Security Fabric servers on a corporate and private network.
At minimum, a typical Bravura One deployment consists of the following:
A Bravura Security Fabric server running the Mobile Worker Service (
mobworker).This service works in conjunction with the Bravura One mobile proxy server to allow the Bravura One app on mobile devices to access Bravura Security Fabric servers.
A separate Bravura One mobile proxy server running the Mobile Proxy Service (
mobproxy).The Bravura One mobile proxy server communicates with the Mobile Worker Service (
mobworker) and allows the Bravura One app on mobile devices using a home or public WiFi hot spot or a cell phone data plan to access Bravura Security Fabric servers on a corporate and private network.Optional: A separate Bravura One mobile proxy server running the Mobile Proxy Service (
mobproxy) may be configured to send push notifications to mobile devices for users that have the Bravura One app registered on their devices.Contact support@bravurasecurity.com for assistance with the configuration and access of the Bravura One mobile proxy push notification server.
The architecture diagram below shows one of the solutions for a Bravura One deployment.
The requirements and layout of the Bravura One solution will vary depending on the needs of your organization and network.
The mobile proxy, used to mediate connections between Bravura One on smartphones and Bravura Security Fabric servers which do not have a public URL, is configured with Linux and Apache and the following hardware capacity:
Small instance, minimum setup (for example, supporting up to 5,000 users): Single core CPU, 1 GB RAM, 10GB HDD.
Large instance (for example, supporting 10,000 or more users): Quad-core CPU, 4 GB RAM, 40GB HDD.
At least two mobile proxies should be deployed and load-balanced in all cases for high availability. Adding proxies also has the desirable side effect of increasing capacity.
